Although there are drones that we cannot fly today, we can still reliably process datasets captured by them outside of DroneDeploy.
Supported Cameras and Sensors
Data Processing Compatibility
Recommended Drones
Flight Autonomy
|
|
|
Skydio 2/2+ |
|
Mavic Air 2 One of DJI's latest drones is now supported for all flight plans on iOS devices. |
Enterprise
Matrice 200 and 210 V2 |
|
Matrice 300 The M300 is DJIβs latest commercial drone, and many of our customers are already uploading and processing photos on our platform with this drone. |
Supported Drones - Flight + Processing
Below we've listed the drone type, whether it's supported for flight, processing, or both (indicated by the β for supported), and the mobile compatibility. Drones listed as supported for processing only cannot be flown autonomously in the app, however, you can still upload and process imagery and data collected on these models. For more information on data processing, visit this page.
Drones denoted with a * may require additional information about what features they support or additional notes on how we can best support that hardware. Please click on the link below to learn more.
Drone Type |
Flight |
Processing |
Supported Mobile |
Inspire 2 | β | β | iOS and Android |
Mavic Air | β | β | iOS and Android |
Mavic Air 2* | β | β | iOS only |
Mavic Pro | β | β | iOS and Android |
Mavic Pro Platinum | β | β | iOS and Android |
Mavic 2 Pro (regular + zoom) |
β | β | iOS and Android |
Mavic 2 Enterprise Zoom | β | β | iOS and Android |
Mavic 2 Enterprise Dual | β | β | iOS and Android |
Phantom 4 | β | β | iOS and Android |
Phantom 4 Advanced | β | β | iOS and Android |
Phantom 4 Pro (including Obsidian) |
β | β | iOS and Android |
Phantom 4 Pro V2.0 | β | β | iOS and Android |
Matrice 100 | β | β | iOS and Android |
Matrice 200 | β | β | iOS and Android |
Matrice 210 | β | β | iOS and Android |
Matrice 210 RTK | β | β | iOS and Android |
Matrice 200 V2 | β | β | iOS and Android |
Matrice 210 V2 | β | β | iOS and Android |
Matrice 210 RTK V2 | β | β | iOS and Android |
Matrice 300 RTK* | β | β | iOS only |
Skydio 2* | β | β | iOS only |
Skydio 2+* | β | β | iOS only |
Skydio X2 | β | N/A | |
Skydio X2E | β | N/A | |
Inspire 1 | β | N/A | |
DJI Air 2S | β | β | iOS Only |
Mavic Mini | β | N/A | |
Mavic Mini 2 | β | N/A | |
Mavic 3 | β | N/A | |
Mavic 2 Enterprise Advanced | β | N/A | |
Phantom 3 and prior | β | N/A | |
Matrice 600 Pro | β | N/A | |
Wingtra | β | N/A | |
Parrot | β | N/A | |
Yuneec | β | N/A | |
Flyability Elios | β | N/A | |
Autel | β | N/A | |
SenseFly | β | N/A |
Supported Cameras & Lenses
Drone Model | Cameras | Lenses |
---|---|---|
Inspire 2 | X4S X5S X7 |
X5S Lenses: - DJI MFT 15mm F1.7 ASPH - OLYMPUS M.12mm F2.0 - OLYMPUS M.45mm F1.8 (Not supported for Panorama flights) X7 Lenses: - DJI DL-S 16mm F2.8 ND ASPH - DJI DL 24mm F2.8 LS ASPH - DJI DL 35mm F2.8 LS ASPH - DJI DL 50mm F2.8 LS ASPH |
Matrice 100 | X3 X5 |
X5 Lenses: - DJI MFT 15mm F1.7 ASPH |
Matrice 200/210/210RTK | X4S X5S XT XT1 XT2* |
X5S Lenses: - DJI MFT 15mm F1.7 ASPH - OLYMPUS M.12mm F2.0 - OLYMPUS M.45mm F1.8 (Not supported for Panorama flights) The X7 exhibits behavior when used on the M200/210 line that prevents normal operation so it is not supported for this line. Z30 - Zoom Camera - Supported for manual capture only |
Matrice 300RTK |
H20 H20T |
DroneDeploy only supports the H20 and H20T payloads at this time. (The P1, XT2, Z30, and L1 payloads are NOT supported at this time for flight. Processing is supported when flown in DJI GS Pro. |
Note: All "Officially Supportedβ cameras and Lenses are tested with DroneDeploy rigorously. Your results with cameras others than those listed above may vary.
*When using XT2, both RGB and Thermal imagery is saved to the SD cards.
Data Processing Compatibility
The DroneDeploy Map Engine lets paying customers upload and process your imagery from any UAV setup with embedded geotags. Once the data has been processed, you will also be able to make use of all the additional DroneDeploy functionality (such as sharing, annotations, and analysis).
Processing imagery from the Phantom 4 Multispectral, MicaSense, SenseFly, Mavic Air 2 or the WingtraOne is officially supported.
RTK processing from DJI drone image sets not taken in DroneDeploy can be processed on Business plans and above.
Using Map Engine does not require any app, just data.
All images must have latitude, longitude and altitude in the GPS EXIF data
All images should be facing the area of interest
All images should have significant overlap (more than 60% side and frontlap, 75% for agricultural or homogeneous imagery)
There must be at least 10 images
To begin, please see How to Process Datasets.
